Polyester Molded Fabric For Paper Machine Mills Air Infiltration 4550-9000 M3/m2 0.2kg

Product Categories

Conveyor Wire Mesh Belt [148]
Spiral Mesh Belt [93]
Flat Wire Mesh Belt [81]
Chain Mesh Conveyor Belt [133]
Flat Flex Conveyor Belt [108]
Compound Balanced Belt [93]
Plate Conveyor Belt [36]
PTFE Conveyor Belts [47]
Polyester Mesh Belt [150]
Polyester Sludge Dewatering Belt [96]
Nylon Filter Mesh [130]
Screen Printing Mesh [29]
Stainless Steel Woven Wire Mesh [97]
Architectural Wire Mesh [23]
Polypropylene Filter Cloth [48]
Polyester Dryer Screen [40]
Polyester Forming Fabric [40]

Hebei Reking Wire Mesh Co.,Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Polyester Molded Fabric For Paper Machine Mills Air Infiltration 4550-9000 M3/m2 0.2kg

Brand Name : RK

Model Number : NM02

Place of Origin : China

MOQ : 1square meetr

Price : 1.4-2USD/square meter

Payment Terms : L/C,T/T,Western Union

Supply Ability : 10000 square meter per month

Delivery Time : 5-15 work days

Packaging Details : woven bag+carton

Weight : 0.2kg

Papermaking weight : 1.1kg/m2、1.4kg/m2、1.7kg/m2、1.9kg/m2

Papermaking strength (N/cm) : 1.7-3mm

Air infiltration : 4550-9000 (m3/m2)

Contact Now

Polyester molded fabric used in paper machine mills (factories)
Product Introduction:

Polyester mesh features high strength, excellent chemical resistance, and good dimensional stability. With fine filtration precision, it's widely used in papermaking, mining, and food industries.

Parameter table

Wire Diameter(mm)			Tensile Strength (N/cm)	Weight Kg/m²	Thickness mm	Air Permeability m³/m²h	CFM 127/pa
Spiral wire	Connection wire	Filter material monofilament	Tensile Strength (N/cm)	Weight Kg/m²	Thickness mm	Air Permeability m³/m²h	CFM 127/pa
0.50	0.80	0.60*3	1800	1.50	2.1	4480	280
0.68	0.90	0.80*4	2000	2.0	2.45	6080	380
0.68	0.90	0.90*3	2000	190	2.45	5760	360
0.68	0.90	0.80*3	2000	1.85	2.45	7750	484
0.68	0.90	Flat wire2.10.80	2000	1.80	2.45	9oo⁰	563
0.68	0.90	Flat wire2.40.88	2000	1.85	2.45	8000	500
0.68	0.90	Conductive carbon wire	2000	1.60	2.45	10000	625
0.90	0.90	0.90*3	2300	2.30	3.03	7500	468
0.90	1.10	1.04	2000	2.40	3.15	6240	390
0.90	1.10	1.23	2000	2.25	3.15	6240	390
1.0	0.90	1.0*3	2000	2.50	3.60	5000	315
1.20	1.30	1.2'3	2600	2.85	4.30	7500	468

Product application
1. Polyester mesh is widely used in the paper - making industry as a crucial dehydration material, playing a key role in the formation and dehydration of paper sheets.
2. In the sewage treatment industry, polyester mesh is applied for filtering and separating impurities to help purify wastewater.
3. The food industry utilizes polyester mesh for tasks such as sieving flour and filtering fluids during food processing to ensure product quality.
4. Polyester mesh is employed in the pharmaceutical industry for filtration and separation in the production process, contributing to the quality and safety of drugs.
5. In the printing industry, polyester mesh is used for screen - printing, allowing for the precise transfer of ink onto various materials like textiles, glass, and plastics.

Product advantage

1. Superior Strength: Exhibits high tensile and abrasion resistance, ensuring long - lasting performance.
2. Chemical Stability: Resistant to acids, alkalis, and most chemicals, suitable for harsh environments.
3. Precise Filtration: Offers consistent mesh openings for accurate separation and efficient filtration.
4. Thermal Resistance: Maintains dimensional stability under a wide temperature range, preventing deformation.
5. Easy Maintenance: Smooth surface reduces clogging, facilitating cleaning and extending service life.
6. Cost - Effective: High durability and low replacement frequency bring long - term economic benefits.

We' re professional manufacturer& supplier of Nylon filter mesh& Polyester filter mesh.
With all available items and size you need.

Packing & Delivery

The common shipping:

1.for small quantity, shipped by courier.
2.for large quantity, shiped by air or by sea.
3.tracking number will be emailed to you after order has been shipped.
4.If you have forwarder in China, we can send to your forwarder for free.
